Shortlisted Project – 2014-2016 Award Cycle: King Fahad National Library, Riyadh, Saudi Arabia
The King Fahad National Library is one of the most important cultural buildings in the Kingdom of Saudi Arabia. It was completed and went into use for its intended purpose in November 2013. The design of King Fahad National Library functions as the central driving force behind a piece of urban development and rearrangement, and combines the challenge of designing within the existing building stock with respect for Arabian culture.
The cuboid shape of the new building surrounds the old 1980s library building on all sides, thus giving the National Library a new appearance in the cityscape. It is clad by lozenge-shaped textile awnings, which playfully combine revelation and concealment.
White membranes, supported by a three-dimensional, tensile-stressed steel cable structure, act as sunshades and reinterpret the Arabian tent structure tradition in a low-energy way.
One particular challenge for the facade is the wide range of temperatures in Riyadh. In summer the steel cables can heat up to a temperature of 80°C and will expand while in winter they can shrink because of night time temperatures sometimes below zero. These effects had to be taken into account in optimising the tension of the cables. Thermal comfort was increased and energy consumption significantly reduced by layered ventilation and floor cooling for the first time in the Arab world.
The old building is now an internal stack, forming the centre of knowledge within the new library. Its dome has been reconstructed in steel and glass to bring in daylight and the former roof of the existing building now provides a well-lit reading landscape.
The main entrance hall is on the ground floor, and a separate area for women is provided on the first floor.
Project Video
An imaginative expansion that doubles available space and provides a new skin for an existing structure.
Project Gallery
King Fahad National Library with landscaped public square. AKAA / Cemal Emden
Night view of the facade. AKAA / Cemal Emden
The square shaped new building is covered by a filigree sun protection textile façade following traditional islamic architectural patterns and linking them with state of the art technology. AKAA / Cemal Emden
The old building is integrated into the new one, and now operates as an internal stack. AKAA / Cemal Emden
White membranes gently distribute the indirect daylight throughout the entire interior. AKAA / Cemal Emden
The existing dome, originally in concrete, has been reconstructed in steel and glass to allow daylight in its centre. It is still a symbol of the library. AKAA / Cemal Emden
